SparkFun Ultrasonic Distance Sensor - TCT40 (Qwiic) Ultrasonic Distance Sensor - HC-SR04 Non-Contact Distance Measurement - Operating Voltage 3.3V - Board Dimensions: 1.75 in x 0.85 in

The SparkFun Qwiic Ultrasonic Distance Sensor, a user-friendly upgrade to the popular HC-SR04 sensor, offers non-contact distance measurement from 2cm to 400cm with an accuracy of 3mm. This sensor is designed to seamlessly integrate with the Qwiic ecosystem for I2C communication, making it a breeze to add to your existing projects and daisy-chain with other Qwiic components.If you prefer to bypass the Qwiic connector and I2C, you can also access the VCC, Trigger, Echo, and Ground pins broken out on the board's edge. Please be aware that this ultrasonic sensor comes uncalibrated, and you will need to manipulate the raw output for your specific application.With its wide range of applications, the SparkFun Qwiic Ultrasonic Distance Sensor is a versatile tool for robotics projects, obstacle avoidance systems, and any application that requires accurate distance measurement without physical contact. Its adaptability makes it a valuable addition to your toolkit. The SparkFun Qwiic Connect System is an ecosystem of I2C sensors, actuators, shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch, 4-pin JST connector. This reduces the amount of required PCB space, and polarized connections mean you can’t hook it up wrong.

• Non-contact distance readings: From 2 cm to 400 cmIncludes: 1x Ultrasonic Distance Sensor - HC-SR04; 1x Right-Angle Header - 4-pin
• Includes: 1x Ultrasonic Distance Sensor - HC-SR04; 1x Right-Angle Header - 4-pin
• Features: Operating Voltage 3.3 V; Detecting Angle: 80 degrees; Sensor range: 2 cm to 400 cm; Accuracy: 3 mm; MCU on board: STM8L051F3; Default I2C Address: 0x2F; Dimensions: 1.75 in x 0.85 in
• Two Qwiic connectors: Seamlessly integrate I2C communication; Easy to connect existing projects and/or daisy-chain other Qwiic components; Can’t hook it up wrong
• Extensive applications: Measure distance reliably without actual contact; Robotics; Obstacle avoidance
